PRODUCT INFORMATION

Introduction

small metal sheet slitting slitter machine with manual cutting blade , manual slittling machine

Slitting machine is used to slit PPGI coil, aluminum coil, galvanized coil, stainless steel, carbon steel and other coils into several small strips along the length direction. The slitting ling mainly consists of uncoiler, leveling system, slitting system, shearing system, damping structure and recoiler and so on. We can design and manufacture different specification according to different requirement of the client.

Machine Parameters

It could be used to process the thickness from 0.2 to 1.2mm and the coil width to 1250mm width. The machine slitting speed can reach 15 to 20 meter per minute.

Material: PPGI, GI, AI, copper, etc.
Thickness 0.4mm-1.0mm
Width: 500mm-1250mm
Outer Diameter: 1300mm
Inner Diameter: 508mm
Weigth 5T
Way of cutting: Feed cutting
Slitting strips: Max 10 strips
Stripe width Min 60mm
Re coiler diameter: 508mm
Speed 0-20m/min

This slitting line is for the thin coil material, in our website, there are more types slitting machine for your reference, For more information, please contact with us. We will provide you with high quality customized machine and suitable solution according to your requirement.
